INTELLIGENT PUMPING SYSTEMS

Streamlined integration of components

Benefits

› Versatile designs

› High quality construction

› Simplified installation with less onsite labor

Optimized pump systems for chilled & condenser water loops

pump skid.PNG

Directly Interface with the Chiller built-in plant manager. Single point responsibility for Chiller + Controls + Pumps Backed up by Daikin Warranty and Service Network.

BENEFITS

1. Single electrical connection

2. Simplified installation, startup and commisioning.

3. Compact footprint

4. Integrated control & Instrumentation

5. Fully adaptable to your application









STANDARD DESIGN INCLUDES:

• Base mounted, end suction pumps

• Daikin Intelligent Pump Manager Controller

• Suction Diffusers

• Triple duty valves

• Manual Gauges

• Pump common discharge header

• Pump common suction header

• Lifting lugs

TECHNICAL DATA

All Daikin skids are assembled on a steel base with or without enclosure. They arrive on site pre-wired, pre-piped and pre-commissioned, eliminating the scheduling challenges and cost overruns of a site-built system.



System Conditions Range
System head (bars) 3 to 6
System flow rate (Ips) up to 380
Number of pumps 2 to 5
Motor power (kW) 10 to 200
Optional Components
Vertical inline or split case pumps
Variable frequency drives (VFD)
Power distribution
Intelligent Pump Manager & instrumentation
Air separator
Pressurization Unit
Expansion tank
Suction diffusers
Check valves
Chemical pot feeder
Glycol feeder
Buffer tank
Plate Heat Exchanger
Inertia Base
Insulation
Cladding
Daikin Pump Skid-21.png

Standard Pump Skid





pump skid with optional skid.PNG

Pump skid with / Optional components options



SKID DIMENSIONS

*Dimensions shown for standard skid systems

Header Size (mm) L (m) W (m) H (m)
150 2.1 2.6 2.3
200 2.1 2.6 2.3
250 2.5 2.7 2.5
300 2.5 3.3 2.5

2-Pump Systems

Header Size (mm) L (m) W (m) H (m)
200 3 2.6 2.3
250 3.5 2.6 2.3
300 3.7 2.7 2.5
350 3.7 2.7 2.5
400 3.7 3.3 2.5

3-Pump Systems

Header Size (mm) L (m) W (m) H (m)
250 4 2.6 2.3
300 4.5 2.6 2.3
350 4.5 2.6 2.3
400 4.9 2.7 2.5
450 4.9 3.3 2.5

4-Pump Systems

Types


Energy transfer station skids



air cooler.PNG

Air-cooled Chiller Skid

pump skid1.PNG

Pumping skids



heating skid1.PNG

Custom Process Cooling/Heating Skid
